Scope of application:
Printing of glass and plastic containers such as wine bottle cap, syringe, pen tube, lipstick tube, opener, cream bottle, water cup, etc.
Function Description:
1. Automatic feeding system, which can manufacture automatic feeding system according to products;
2. Automatic flame treatment;
3. Mechanical positioning and automatic printing;
4. European or American UV system;
5. Panasonic PLC, face touch screen control;
6. Closed equipment, safe and clean.
&Nbsp; technical parameters:
|
speed
|
4200
|
|
Product size
|
Ø10-110mm H: 35-260mm
|
|
Pattern size
|
Ø10-110mm H: 35-185mm
|
|
UV power
|
2-3.6Kw
|
|
pressure
|
6-7Bar
|
|
Gas pressure
|
1.5Bar
|
|
Power Supply
|
380V, 3 phases
|
|
Body size
|
1100x1300x1700mm
|
|
weight
|
600kgs
|
